4 Button Delay Timer Relay Module 6 To 30v Dc Adjustable Timer Relay Module In Pakistan
Digital 4 Button Delay Timer Relay 6-30V Cycle Delay Timer Switch is a timer relay suitable for your Egg incubator and other time-related Devices. The timer relay module is a Digital display Led Home Automation Delay Timer Control Switch Module Timer Controller, Operating voltage: 6-30V, support micro USB 5.0V power supply, Output capability: Can control the device within DC 30V 5A or AC 220V 5A. This best incubator timer controller can be applied to many fields; there is a wide range of applications. Programmable Triggered Timing Circuit board Hw-521 35238mp.
Digital 4 Button Delay Timer Relay 6-30V is a timer relay suitable for your Egg incubator and other time-related Devices. The timer relay module is a Digital display Led Home Automation Delay Timer Control Switch Module Timer Controller.
Specifications of 6 To 30v Dc Adjustable Delay Timer Relay Module:
- Operating voltage: 6-30V Support Micro USB 5.0V power supply
- Trigger signal source: Active-high 3.0V-24V have optocoupler isolation, can improve the system’s anti-jamming capability
- Output capability: DC 5-30V 10A & AC 220V 10A.
- Quiescent current: 20mA;
- Operating current: 50mA
- Service life: more than 10 million times
- Working temperature: -40°c ~ 85 °c
- Dimension: 62×38×17mm.
- Special Note: The output of the replay is passive contact, without voltage output, just for controlling the on or off of a single circuit.
- Timing range:0.1 seconds To 999 minutes (max.) continuously adjustable
Features Of 4 Button Delay Timer Relay Module DC 6-30V Cycle Delay Timer Switch:
- Wide voltage power supply (6 ~ 30V), supports micro USB 5.0V power supply, easy to use;
- The interface is clean, simple, powerful, and easy to understand, can meet almost all your needs;
- With emergency stop function (“STOP” button) and reverse polarity protection which can avoid burning by reverse connection.
- Adding sleeping mode, when the mode is enabled, if there is no operation within 5 minutes, the display will be turned off automatically, press any button will wake it up;
- You can set different parameters of OP, CL, LOP, which are independent of each other and are stored separately;
- All the parameter settings will be stored automatically when power is off.
- With optocoupler isolation, enhanced anti-jamming capability, industrial-grade board. The parameter setting will be stored forever when power is off.
- 1 x 4 Button Delay Timer Relay Module In Pakistan
