UNI-T 30V 5A Variable DC Regulated Power Supply UTP3315TFL-II In Pakistan

This is a UTP3315TFL-II Variable power supply that can give 0 to 30v and can provide 0 to 5a. UTP3315TFL II adjustable dc power supply has an over-current limitation, which means it will follow output flowing current and limit it to the set value by decreasing its output voltage.

Specifications of UNI-T UTP3315TFL-II 30V 5A Variable DC Regulated Power Supply For Mobile Repairing:

• Model: UTP3315TFL-II
• Output Voltage: 0~30V
• Output Voltage: 0~5A
• Load Effect: ≤1×10-4 +2mV
• Ripple and Noise: ≤0.3mV
• Power Effect: ≤1×10-4 +2mV
• Indication Method: Digital Display
• Power: 220V±10%,50Hz±4%
• Product Color: Ivory White+Grey
• Product Net Weight: 4kg(about）
• Product Size: 240（depth）mm×160（height）mm×105（width）mm
• Standard Accessories: Power Line
• Standard Packing: Carton, Manual

Features of UNI-T UTP3315TFL-II 30V 5A Variable DC Regulated Lab Bench Power Supply:

1. Single-channel, 3-bit digital display, shows voltage and current simultaneously
2. Voltage display resolution: 100mV; current display resolution: 10mA
3. Voltage output: 0~30V consecutive and adjustable voltage
4. Current output: 0~5A
5. Auto voltage and current stabilization conversion, current limiting protection, undamaged for any external usage

Package Includes:

• 1 x UNI-T UTP3315TFL DC Power Supply
• 1 x Testing Leads
• 1 x Power Cable
• 1 x User Manual
