FNIRSI LCR P1 Multifunction Component Tester Transistor Tester

The FR LCR P1 Digital Transistor Tester is an essential tool for electronics technicians, engineers, and hobbyists who need a quick and accurate way to identify and measure components. This multi-function LCR meter and component analyzer can automatically detect and test a wide range of components including resistors, capacitors, inductors, diodes, triodes, transistors, MOSFETs, SCRs, and more.

With just one button, the device quickly identifies component type and shows pin configuration, values, and other key parameters on a large, easy-to-read color display. It simplifies troubleshooting, circuit design, and component sorting—especially when working with unmarked or unknown parts.

Specification of FNIRSI LCR P1 Multifunction Component Tester Transistor Tester:

1. Brand: FNIRSI
2. Model: LCR-P1
3. Dimensions: 13×8.5×4.5mm
4. Power Supply: Battery
5. Display Type: Digital Only
6. Transistor range: 10 < B < 600
7. Capacitance Range: 25pF-100mF
8. Inductance range: 10μh-1000μh
9. Resistance Range: 0.01Ω-50MΩ
10. Diode Forward voltage: < 4.5V
11. Voltage Regulator Diode: 0.01-4.5V / 0.01-32V
12. Field-Effect Transistor: JFET / IGBT / MOSFET
13. Bidirectional Thyristor Turn-on voltage: < 5V, Gate trigger current < 6mA
14. IR Decoding: NEC protocol IR code
15. Display: 1.44” Color Screen
16. Power Supply: 300mAh lithium battery
17. Operating Temperature: 0~40℃
18. Charging: USB Type-C, 5V/1A
19. Anti-burn protection supported
20. Data Export supported
21. Firmware upgrade supported

Package Includes:

• 1 x FNIRSI LCR P1 Multifunction Component Tester Transistor Tester
