18 Pin IC Socket base adaptor is an 18 pin IC holder, which can be soldered directly onto the PCB. The IC can be removed from this socket when required. The IC is placed on the socket at the time of use. This base acts as a removable IC holder.
The socket is used when the IC is temperature sensitive and the heat from the soldering iron can damage the IC. This socket is used when working with a microcontroller IC and can be removed for programming.
Specifications of 18pin Dip Ic Base Socket Solder Type:
- Model:18pin IC Base
- Current Handling Capacity (A):1
- No. of Contact Points:18
- Contact Material: Phosphor Bronze
- Contact Plating: Tin
- Operating Temperature Range (°C):-25 to 85
- Flammability Rating: UL94V-0
- Color: Black
- Insertion Force:340g max per contact
- Exertion Force:80g max per contact
- Length (mm):23
- Width (mm):10
- Height (mm):4
Feature of 18p Integrated Circuit Base Socket:
- 18 pins.
- JDEC compliant.
- Molded notch for proper orientation.
- Easy to insert and remove ICs.
Package Includes:
- 1 x 18 Pin DIP SIP IC Base Sockets Adaptor Solder Type In Pakistan
