This is a 2-inch O Ring LCD “HMI” touchscreen display compatible with all models of JK SMART BMS. This touch screen can be used to program the parameters into the BMS on the go, without needing to bring along a laptop for programming modifications. You can actively see the status of your batteries, the voltages of each cell, current flow, and many other useful monitoring parameters. This unit is a great addition to a DIY build. JK BMS Accessories 2 Inch LCD With O Ring JK LCD In Pakistan.
Specification of JK BMS Accessories 2 Inch LCD With O Ring:
- Brand: JIKONG
- Power supply voltage (V): 9V-12V
- Display type: O Ring LCD
- Size: 2 inches
- Working temperature/Storage temperature: -20~-70℃/-30~-85~℃
- Working temperature (℃) At 12V voltage, humidity 60% : -20-70
- Storage temperature (℃) : -30-80
- Working humidity (PH) At 25℃: 10%-90%
- When the BMS is turned off, press the button on the left side of the LCD screen for a single time to turn on the BMS.
- When the BMS is on, if the display does not display content, press the switch on the left side of the LCD once, and the LCD will turn on the backlight.
- side of the LCD once, and the LCD turns off the backlight.
- When the BMS is powered on, press and hold the button on the left side of the LCD screen for 2 seconds, and the BMS is powered off.
Package Include:
- 1 x JK BMS Accessories 2 Inch LCD With O Ring JK LCD In Pakistan
